Homepage / Products / Easylube® Automatic Lubricators / Elite Series
USA UL explosion proof certified
European CE certified
Precision gear driven transmitted device
5th generation new operating procedure
Stable, routine and precise grease injection
Guaranteed Lifespan of 5+ Years
 |
IP65 Dustproof and Waterproof Rating Certified |
|---|
 |
The patented grease feedback pressure monitoring system can ensure that grease is added systematically into the bearing for lubrication. |
|---|
 |
24-hour active monitoring, once the equipment is abnormal, it will immediately blink the warning light. |
|---|
 |
The lubricator self-test function can be used to confirm whether the driving system is operating normally or not. |
|---|
 |
The re-greasing interval can be set according to the bearing operating conditions to the range of 1-12 months |
|---|
| Product Number | EL-60/150/250E |
|---|---|
| Product Model | Easylube® 60/150/250 Elite |
| Outlet Diameter | 1/2" PT (M) |
| Grease Volume | 60 / 150 / 250 ml |
| Grease Interval Range | Adjustable from 1 to 12 months |
| Operating Environment Temperature Range | -20 ~ 60°C (-4 ~ 140°F) |
| Pressure Plate Thrust (Piston) | 75 - 150 psi (5 - 10 bar) Automatic adjustment according to bearing's back pressure |
| Product Size (Height x Diameter) | 60 ml：13.9 x 8.9 cm (5.47 x 3.5") 150 ml：16.3 x 8.9 cm (6.4 x 3.5") 250 ml：19.6 x 10.2 cm (7.7 x 4") |
|
Easylube® Original Service Pack
Product Number：ES-60/150/250-XXXX-3B Coding Principles： ES Series + Capacity + Grease Cup Specification + Lithium Battery |
Rated Power (Lithium Battery Model / Specification)：
Easylube® P-613B DC 6V × 1500 mAh, UL94-V0 |
| Easylube® Grease Refiller (Grease Specification / Product Name)：
60 ml： ES-60-1000 High Speed Grease Cup ES-60-1500 Multipurpose Grease Cup ES-60-2000 High Performance Grease Cup ES-60-5000 Food Grade Grease Cup ES-60-0000 DIY Empty Grease Cup Kit 150 ml： ES-150-1000 High Speed Grease Cup ES-150-1500 Multipurpose Grease Cup ES-150-2000 High Performance Grease Cup ES-150-5000 Food Grade Grease Cup ES-150-0000 DIY Empty Grease Cup Kit 250 ml： ES-250-1000 High Speed Grease Cup ES-250-1500 Multipurpose Grease Cup ES-250-2000 High Performance Grease Cup ES-250-5000 Food Grade Grease Cup ES-250-0000 DIY Empty Grease Cup Kit |
|
| Hazardous Location Application Specification | File E218441 Class I, Division 2, Groups A, B, C and D |
| CE Certification |
EMC SGS Ref. No.: VTMWH2206000309HEA/2022, TERF2206000807ER RED SGS Ref. No.: VTMWH2206000310HEA/2022 LVD SGS Ref. No.: TESA2206000150ES RoHS ETC Ref. No.: 23-01-QAC-130 |
| Dustproof and Waterproof Grade | IP65 |
