MAX Series
USA UL explosion proof certified
European CE certified
In year 2021, the newest 6th generation distinguished automatic lubricator Easylube® MAX series has been developed. The series can record operation time with its memory function and has an AI controlled electrical system that can detect lithium battery’s power supply automatically. The lubricator also has an additional (Bluetooth Communication) NFC patrol card reader for performing inspection works.
The MAX product series combines the most advanced technologies, it is not only convenient to operate, but also can be used with the smart cloud management software (Easylube® LINK). Such automatic lubrication and inspection operations can promote the reliability of preventive maintenance activities in the factory. It can replace the traditional inspection method of recording on paper completely to make the inspection operation information more true, consistent, and flexible. When the observed value in the inspection operation exceeds the expected standard, corrective actions can be taken immediately. This operation method can often avoid more serious equipment problems.
The MAX product series caters to a very safe and extensive automated operation management needs, and is an indispensable tool for maintenance technicians, engineers, and managers in the factory.
 |
AI electrical control system will automatically detect battery level to repeatedly fully utilize the battery and save cost. |
|---|
 |
Equipped with operation time memory function and by paring with external power supply, it can synchronize power options with the equipment. |
|---|
 |
Built-in NFC sensor chip (RFID), will be paired with inspection software to perform on-site inspection. |
|---|
 |
The patented grease injection pressure monitoring system can ensure that grease is smoothly injected into the bearing for lubrication. |
|---|
 |
The grease injection period can be set according to the lubrication conditions required by the bearing to the range of 0.5-12 months. |
|---|
 |
The lubricator checking mode function can be used to check whether the lubricator is operating normally or not. |
|---|
(Note 1)
| Product Model | EL-60 / 150 / 250 MAX (Note 2) |
|---|---|
| Outlet Diameter | 1/2" PT (M) |
| Grease Volume | 60 / 150 / 250 ml |
| Grease Interval Range | Adjustable from 0.5 to 12 months |
| Operating Environment Temperature Range | -20 ~ 60°C (-4 ~ 140°F) |
| Pressure Plate Thrust (Piston) | 75 - 150 psi (5 - 10 bar) Automatic adjustment according to bearing's back pressure |
| Operation Indicator | Green light：Normal schedule Single orange light：Low battery voltage Orange light：Abnormal grease injection Red light：Grease injection cycle completed |
| Product Size (Height x Diameter) | 13.9 x 8.9 cm (5.47 x 3.5") 16.3 x 8.9 cm (6.4 x 3.5") 19.6 x 10.2 cm (7.7 x 4") |
| Rated Power (Battery Specification) | P-613B Explosion proof lithium battery： DC 6 V, UL94-V0 Flameproof rating |
| Original Equipment Manufacturer Service Pack | Grease Refiller (Grease Specification)
Easylube® 1000 High Speed Grease Easylube® 1500 Multi-Purpose Grease Easylube® 2000 Heavy-Load Grease Easylube® 5000 Food Grade Grease DIY empty grease cup kit |
| Hazardous Location Application Specification | File E218441 Class I, Div. 2, Groups A, B, C and D |
| CE Certification | – (Note 3) |
| Dustproof and Waterproof Grade | IP65 |
Note：
(1) The manufacturer reserves the rights to change the technical specifications without prior notice
(2) 60 MAX, 250 MAX products in development
(3) Pending CE certification
